Test bench for Renault gearboxes

Gear linkage test bench

Gear linkage test bench is ready! It makes easier to examine the gear linkage movement. The manufacturing process - including designing, welding, assembly and painting - was made by me.
Main features:
- the position of gearstick housing and gearbox is fully adjustable compared to each other
- capable of mounting newer Renault gearboxes (JB, JC, TL4, ND0 etc.)
- moveable and brakeable
- easily adjustable
- mounted gearbox may be rotated around its axis
- beared slewing unit
- simple but innovative appearance
- robust and rigid design

10/12/11
